Reference Angle Calculator (with Coterminal Angles)

Geometry & trigFreeNo sign-up

A reference angle calculator finds the acute angle between an angle’s terminal side and the x-axis. For 210°, first see that 210° is in Quadrant III, then subtract 180°: 210° − 180° = 30°, which is π/6 in radians. Negative angles and angles over 360° are first reduced to a coterminal angle between 0° and 360°.

Find the reference angle
Any angle works: negative (−510), larger than 360 (765), decimals (112.5), fractions (45/2) or degrees and minutes (150°30′).
Try:
Reference angle
θ′ = 30°

The reference angle of 210° is 30° (π/6 rad). The angle ends in Quadrant III.

Reference angle (degrees)30°
Reference angle (radians)π/6 ≈ 0.5236
QuadrantQuadrant III
Coterminal angle, 0° to 360°210°
Coterminal angle, 0 to 2π7π/6
Other coterminal angles570° and −150°
Signs (sin, cos, tan)sin −, cos −, tan +
sin θ−1/2
cos θ−√3/2
tan θ√3/3
0π/2 (90°)π (180°)3π/2 (270°)210°θ′Gold arc: the rotation from the positive x-axis (counterclockwise). Green: the terminal side. The dot is the point (cos θ, sin θ) = (−√3/2, −1/2). Yellow wedge: the reference angle θ′, measured to the nearest part of the x-axis.
Show steps
  1. A reference angle θ′ is the acute angle between the terminal side of θ and the x-axis. It is always between 0° and 90° (0 and π/2), and it is never negative.
  2. 210° is already between 0 and 360°, so use it as it is.
  3. 210° is between 180° and 270°, so the terminal side is in Quadrant III.
  4. Use the Quadrant III rule θ′ = θ − 180°: θ′ = 210° − 180° = 30°.
  5. In radians: 30° × π/180 = π/6 ≈ 0.5236.
  6. Only tangent (and cotangent) is positive in Quadrant III (All Students Take Calculus, starting in Quadrant I and going counterclockwise). So sin θ = −sin θ′, cos θ = −cos θ′ and tan θ = tan θ′.
  7. With the exact values for 30°: sin θ = −1/2, cos θ = −√3/2, tan θ = √3/3.

Reference angles let you find the trig value of any angle from the first-quadrant values: use θ′ for the size and the quadrant for the sign.

Reference Angle Calculator (with Coterminal Angles)
Embed this calculator on your site

Free to use on class pages, blogs and course pages. Copy the code below and paste it into your page:

What is a reference angle?

The reference angle θ′ of an angle θ in standard position is the smallest positive angle between the terminal side of θ and the x-axis. It is always between 0° and 90° (0 and π/2). Reference angles let you work out sin, cos and tan of any angle from the first-quadrant values you already know: the reference angle gives the size of the value and the quadrant gives the sign.

How to use the reference angle calculator

  1. Choose Angle in degrees or Angle in radians.
  2. Type any angle. Degrees can be negative, larger than 360, decimals, fractions or degrees and minutes. Radians can use π (11π/6, pi/4) or be plain numbers such as 2.5.
  3. Read the reference angle in both degrees and exact radians, the quadrant, coterminal angles, the signs of sin, cos and tan, and the exact trig values for special angles.
  4. Check the unit circle picture, where the yellow wedge is the reference angle, and open Show steps for the full working.

Reference angle formulas by quadrant

First reduce θ to a coterminal angle between 0° and 360° (0 and 2π). Then use the rule for its quadrant:

Quadrant Angle range Reference angle (degrees) Reference angle (radians) Positive functions
I 0° to 90° θ′ = θ θ′ = θ all
II 90° to 180° θ′ = 180° − θ θ′ = π − θ sin
III 180° to 270° θ′ = θ − 180° θ′ = θ − π tan
IV 270° to 360° θ′ = 360° − θ θ′ = 2π − θ cos

The last column is the ASTC rule, often remembered as “All Students Take Calculus”. Angles on an axis (0°, 90°, 180°, 270°) are quadrantal angles: their reference angle is 0° on the x-axis and 90° on the y-axis.

Coterminal angles first: negative angles and angles over 360°

Coterminal angles share the same terminal side. They differ by whole turns of 360° (2π). To find the one between 0° and 360°, add or subtract 360° until you land in that range:

  • 765° − 2 × 360° = 45°, so the reference angle is 45°.
  • −510° + 2 × 360° = 210°, which is in Quadrant III, so the reference angle is 210° − 180° = 30°.
  • 17π/6 − 2π = 5π/6, which is in Quadrant II, so the reference angle is π − 5π/6 = π/6.

You do not need to reduce a negative angle by hand if you prefer to sketch it: −60° ends in Quadrant IV, 60° below the x-axis, so its reference angle is 60°.

Worked examples

Degrees: 150°

150° is between 90° and 180°, so it is in Quadrant II. θ′ = 180° − 150° = 30°. Since only sine is positive in Quadrant II, sin 150° = sin 30° = 1/2 and cos 150° = −cos 30° = −√3/2.

Radians: 5π/4

5π/4 is between π and 3π/2, so it is in Quadrant III. θ′ = 5π/4 − π = π/4, which is 45°. In Quadrant III only tangent is positive, so tan(5π/4) = 1 while sin(5π/4) = cos(5π/4) = −√2/2.

A large angle: 480°

480° − 360° = 120°, in Quadrant II. θ′ = 180° − 120° = 60° (π/3). So sin 480° = sin 60° = √3/2.

Radians without π: 4

π ≈ 3.1416 and 3π/2 ≈ 4.7124, so 4 radians is in Quadrant III. θ′ = 4 − π ≈ 0.8584 radians, about 49.18°.

Reference angles of common angles

Angle Radians Quadrant Reference angle
120° 2π/3 II 60° = π/3
135° 3π/4 II 45° = π/4
150° 5π/6 II 30° = π/6
210° 7π/6 III 30° = π/6
225° 5π/4 III 45° = π/4
240° 4π/3 III 60° = π/3
300° 5π/3 IV 60° = π/3
315° 7π/4 IV 45° = π/4
330° 11π/6 IV 30° = π/6

Common mistakes with reference angles

  • Measuring to the y-axis. The reference angle is always measured to the x-axis. For 120°, it is 60°, not 30°.
  • Giving a negative answer. For −60°, the reference angle is 60°, not −60°.
  • Skipping the coterminal step. 480° − 180° = 300° is wrong; reduce to 120° first.
  • Mixing units. In radians use π, not 180: the Quadrant II rule is π − θ.
  • Forgetting the sign. The reference angle gives the size of a trig value; the quadrant gives its sign. cos 150° is −√3/2, not √3/2.

Reference angles practice quiz: 10 questions

Test yourself with 10 multiple-choice questions. Choose an answer and press Submit to see if you are right and why. Your score appears at the end.

Question 1 of 10
1. What is the reference angle of 135°?

Found a mistake? Let us know!

2. What is the reference angle of 300°?

Found a mistake? Let us know!

3. What is the reference angle of −150°?

Found a mistake? Let us know!

4. What is the reference angle of 7π/6?

Found a mistake? Let us know!

5. What is the reference angle of 2π/3?

Found a mistake? Let us know!

6. What is the reference angle of 860°?

Found a mistake? Let us know!

7. In which quadrant is only cosine positive?

Found a mistake? Let us know!

8. Use the reference angle to find cos 240°.

Found a mistake? Let us know!

9. Which angle is coterminal with 45°?

Found a mistake? Let us know!

10. What is the reference angle of 180°?

Found a mistake? Let us know!

Frequently asked questions

How do you find a reference angle?

Reduce the angle to a coterminal angle between 0° and 360°, find its quadrant, then apply the rule: θ in Quadrant I, 180° − θ in II, θ − 180° in III and 360° − θ in IV. For 225°, that gives 225° − 180° = 45°.

How do you find a reference angle without a calculator?

Sketch the angle on coordinate axes, see which quadrant it ends in, and measure the gap to the nearest part of the x-axis. 150° is 30° short of 180°, so its reference angle is 30°. −60° is 60° below the positive x-axis, so its reference angle is 60°.

How do you find a reference angle in radians?

Use the same rules with π: θ, π − θ, θ − π or 2π − θ. 5π/4 − π = π/4, and 2π − 11π/6 = π/6.

How do you find the quadrant and reference angle of an angle?

Reduce it first, then match the range. 480° − 360° = 120°, which is between 90° and 180°, so it is in Quadrant II with reference angle 180° − 120° = 60°.

How do you find a reference angle using a calculator?

Choose degrees or radians, type the angle and press Calculate. For −510°, the calculator above shows the coterminal angle 210°, Quadrant III and reference angle 30° (π/6), with each step.
