A hyperbola calculator reads a and b from the standard form and finds the rest with c² = a² + b². For x²/9 − y²/16 = 1, a = 3 and b = 4, so c = √(9 + 16) = 5. The vertices are (±3, 0), the foci are (±5, 0), the asymptotes are y = ±(4/3)x and the eccentricity is e = c/a = 5/3 ≈ 1.67.

Hyperbola calculator: what do you know?
Type either form: (x – 3)^2/9 – (y + 2)^2/16 = 1, y^2/4 – x^2/12 = 1, or 9x^2 – 4y^2 + 36x + 8y – 4 = 0. Use ^2 or ² for squares.
Try:
Hyperbola in standard form
(x − 3)²/9 − (y + 2)²/16 = 1

Center (3, −2), a = 3, b = 4, c = 5

The hyperbola (x − 3)²/9 − (y + 2)²/16 = 1 has center (3, −2), a horizontal transverse axis, vertices (6, −2) and (0, −2), foci (8, −2) and (−2, −2) and asymptotes y + 2 = ±(4/3)(x − 3). Eccentricity e = 5/3 ≈ 1.67.

Standard form(x − 3)²/9 − (y + 2)²/16 = 1
General form16x² − 9y² − 96x − 36y − 36 = 0
Center (h, k)(3, −2)
Eccentricity e5/3 ≈ 1.67
a (center to vertex)3
b (center to co-vertex)4

Key points

Transverse axisHorizontal (opens left and right)
Vertices(6, −2) and (0, −2)
Co-vertices(3, 2) and (3, −6)
Foci(8, −2) and (−2, −2)
c (center to focus)5
a², b², c²9, 16, 25

Asymptotes

Asymptotesy + 2 = ±(4/3)(x − 3)
Asymptote slopes± 4/3 ≈ 1.33
Asymptote 1y = (4/3)x − 6
Asymptote 2y = −(4/3)x + 2

Focus and graphing facts

Latus rectum length 2b²/a32/3 ≈ 10.67
Directricesx = 24/5 and x = 6/5
Transverse axis length 2a6
Conjugate axis length 2b8
Distance between foci 2c10
x-intercepts(3 ± 3√5/2, 0) ≈ (6.35, 0) and (−0.35, 0)
y-intercepts(0, −2) (touches)
Domainx ≤ 0 or x ≥ 6
Rangeall real numbers
Parametric formx = 3 + 3 sec t, y = −2 + 4 tan t
48−4F₁F₂(3, −2)Green: the two branches, with the vertices as green dots. Dashed red: the asymptotes, which pass through the corners of the dashed blue box (2a by 2b, with the open blue dots at the co-vertices). Gold: the foci. Dashed purple: the directrices.
Show steps
  1. Write the equation in general form with whole-number coefficients: 16x² − 9y² − 96x − 36y − 36 = 0. The x² and y² coefficients have opposite signs, so it is a hyperbola.
  2. Group the x terms and the y terms, factor out the squared coefficients and move the constant: 16(x² − 6x) − 9(y² + 4y) = 36.
  3. Complete each square. Half of −6 is −3; its square is 9, which adds 16 × 9 = 144 to the left side. Half of 4 is 2; its square is 4, which adds −9 × 4 = −36. Add the same amounts to the right side.
  4. Write each group as a square: 16(x − 3)² − 9(y + 2)² = 36 + 144 + (−36) = 144.
  5. Divide both sides by 144 to make the right side 1: (x − 3)²/9 − (y + 2)²/16 = 1. The center is (3, −2) (the signs inside the brackets flip).
  6. The positive term holds x, so the transverse axis is horizontal and the hyperbola opens left and right. The denominator under the positive term is a² = 9, so a = 3; the other denominator is b² = 16, so b = 4.
  7. For a hyperbola, c² = a² + b² (add, unlike an ellipse) = 9 + 16 = 25, so c = 5. Vertices are a units from the center along the transverse axis, foci are c units away, and co-vertices are b units away on the conjugate axis.
  8. Asymptotes pass through the center with slopes ±b/a = ±4/3 ≈ 1.33: y + 2 = ±(4/3)(x − 3), that is y = (4/3)x − 6 and y = −(4/3)x + 2.
  9. Eccentricity e = c/a = 5/3 ≈ 1.67. It is always greater than 1 for a hyperbola; larger values mean wider-opening branches.
  10. Latus rectum (the chord through a focus, perpendicular to the transverse axis) = 2b²/a = 32/3 ≈ 10.67. Directrices: x = 3 ± a²/c, so x = 24/5 and x = 6/5.

Check: for every point on the hyperbola, the distances to the two foci differ by exactly 2a = 6.

Hyperbola Calculator — Vertices, Foci & Asymptotes
Embed this calculator on your site

Free to use on class pages, blogs and course pages. Copy the code below and paste it into your page:

How to use the hyperbola calculator

  1. Choose what you know: an Equation in standard or general form, the Center, a & b with the direction the hyperbola opens, or two Vertices & a focus.
  2. Type the equation or the numbers. Fractions such as 9/4 and roots such as √10 or 2√5 work for a and b.
  3. Read the standard and general forms, center, a, b, c and eccentricity, then the vertices, co-vertices, foci, asymptote equations, latus rectum, directrices, intercepts, domain and range.
  4. Check the graph, which draws both branches, the asymptotes and the 2a-by-2b box, and open Show steps for the completing-the-square work and every formula with your numbers.

Key parts of a hyperbola

A hyperbola is the set of points whose distances to two fixed points, the foci, differ by the same amount, 2a. It has two separate branches. Its parts:

  • Center (h, k): the midpoint between the vertices and between the foci.
  • Vertices: the turning points of the two branches, a units from the center along the transverse axis.
  • Co-vertices: b units from the center along the conjugate axis. They are not on the curve, but they set the slope of the asymptotes.
  • Foci: c units from the center, with c² = a² + b². The foci lie outside the vertices.
  • Asymptotes: two lines through the center that the branches approach but never touch.
  • Eccentricity e = c/a: always greater than 1. The larger it is, the wider the branches open.
  • Latus rectum (length 2b²/a) and directrices (lines at distance a²/c from the center, between the center and each vertex).

Hyperbola equation: standard form and general form

A hyperbola that opens left and right has standard form (x − h)²/a² − (y − k)²/b² = 1. One that opens up and down has (y − k)²/a² − (x − h)²/b² = 1. The positive term tells you the direction, and a² is always under it. Unlike an ellipse, a can be smaller than b.

Expanding and clearing fractions gives the general form Ax² + Cy² + Dx + Ey + F = 0, where A and C have opposite signs. Same signs mean an ellipse or circle, and a missing square term means a parabola.

Property Horizontal transverse axis Vertical transverse axis
Vertices (h ± a, k) (h, k ± a)
Co-vertices (h, k ± b) (h ± b, k)
Foci (h ± c, k) (h, k ± c)
Asymptotes y − k = ±(b/a)(x − h) y − k = ±(a/b)(x − h)
Directrices x = h ± a²/c y = k ± a²/c
c and e c² = a² + b², e = c/a

Worked example: general form to standard form

  1. Start with 16x² − 9y² − 96x − 36y − 36 = 0.
  2. Group and factor: 16(x² − 6x) − 9(y² + 4y) = 36.
  3. Complete the squares: (−3)² = 9 inside the x bracket adds 16 × 9 = 144; 2² = 4 inside the y bracket adds −9 × 4 = −36. So 16(x − 3)² − 9(y + 2)² = 36 + 144 − 36 = 144.
  4. Divide by 144: (x − 3)²/9 − (y + 2)²/16 = 1.
  5. The center is (3, −2), the x term is positive (opens left and right), a = 3, b = 4 and c = √(9 + 16) = 5.

The vertices are (6, −2) and (0, −2), and the foci are (8, −2) and (−2, −2). The asymptotes are y + 2 = ±(4/3)(x − 3), or y = (4/3)x − 6 and y = −(4/3)x + 2. The latus rectum is 2b²/a = 32/3 ≈ 10.67, and the directrices are x = 3 ± 9/5, that is x = 24/5 and x = 6/5.

Worked example: a vertical hyperbola

For y²/4 − x²/12 = 1 the y term is positive, so the hyperbola opens up and down with a² = 4 and b² = 12. Then a = 2, b = 2√3 and c = √(4 + 12) = 4. The vertices are (0, ±2), the foci are (0, ±4), the eccentricity is 4/2 = 2, and the asymptotes are y = ±(a/b)x = ±(√3/3)x.

Building the equation from vertices and a focus

With vertices (−3, 0) and (3, 0) and a focus at (5, 0), the center is the midpoint (0, 0), a = 3 and c = 5. For a hyperbola b² = c² − a² = 25 − 9 = 16, so the equation is x²/9 − y²/16 = 1. If the focus were between the vertices, c would be less than a and the shape would be an ellipse instead.

How to draw a hyperbola by hand

  1. Plot the center, then the vertices a units along the transverse axis and the co-vertices b units along the other axis.
  2. Draw the box through those four points; it is 2a by 2b.
  3. Draw the diagonals of the box extended in both directions. These are the asymptotes.
  4. Sketch each branch starting at a vertex and bending toward the asymptotes.

On a graphing calculator, solve for y: y = k ± b√((x − h)²/a² − 1) for a horizontal hyperbola, and enter the plus and minus versions as two functions.

Common mistakes with hyperbolas

  • Subtracting for c. For a hyperbola c² = a² + b². Subtraction is the ellipse rule.
  • Assuming a is the larger number. a² goes with the positive term, whatever its size.
  • Swapping the asymptote slope. It is b/a when the hyperbola opens sideways and a/b when it opens up and down.
  • Sign errors in the center. (x + 3)² means h = −3.
  • Dividing by a negative right side and forgetting the swap. If completing the square gives a negative constant, dividing flips which term is positive, so the hyperbola opens the other way.
  • Treating x² − y² = 0 as a hyperbola. With 0 on the right it is just the two asymptotes, y = x and y = −x.

Hyperbola practice quiz: 10 questions

Test yourself with 10 multiple-choice questions. Choose an answer and press Submit to see if you are right and why. Your score appears at the end.

Question 1 of 10
1. For x²/16 − y²/9 = 1, what is c, the distance from the center to each focus?

Found a mistake? Let us know!

2. Which way does y²/25 − x²/4 = 1 open?

Found a mistake? Let us know!

3. What are the asymptotes of x²/9 − y²/16 = 1?

Found a mistake? Let us know!

4. What is the eccentricity of x²/36 − y²/64 = 1?

Found a mistake? Let us know!

5. What is the center of 9x² − 4y² + 36x + 8y − 4 = 0?

Found a mistake? Let us know!

6. Find the foci of (y − 1)²/16 − (x + 2)²/9 = 1.

Found a mistake? Let us know!

7. A hyperbola has vertices (±4, 0) and foci (±5, 0). What is its equation?

Found a mistake? Let us know!

8. What is the length of the latus rectum of x²/4 − y²/12 = 1?

Found a mistake? Let us know!

9. Which equation is a hyperbola?

Found a mistake? Let us know!

10. What is the eccentricity of the rectangular hyperbola x² − y² = 4?

Found a mistake? Let us know!

Frequently asked questions

What is the equation of a hyperbola?

In standard form, (x − h)²/a² − (y − k)²/b² = 1 for a hyperbola that opens left and right, or (y − k)²/a² − (x − h)²/b² = 1 for one that opens up and down. The center is (h, k).

How do you calculate a hyperbola?

Put the equation in standard form, read h, k, a and b, then find c = √(a² + b²). Everything else follows: vertices at distance a, foci at distance c, asymptote slopes ±b/a or ±a/b and e = c/a.

How do you calculate hyperbola foci?

Compute c = √(a² + b²) and move c units from the center along the transverse axis. For x²/9 − y²/16 = 1, c = 5 and the foci are (−5, 0) and (5, 0).

How do you calculate a hyperbola asymptote?

Use y − k = ±(b/a)(x − h) for a horizontal hyperbola or y − k = ±(a/b)(x − h) for a vertical one. For x²/9 − y²/16 = 1 the asymptotes are y = ±(4/3)x.

How do you find the eccentricity of a hyperbola?

Divide c by a. For a = 3 and c = 5, e = 5/3 ≈ 1.67. It is always greater than 1; when a = b (as in x² − y² = 1), e = √2 and the asymptotes are perpendicular.

How do you graph a hyperbola on a graphing calculator?

Solve the equation for y and enter both signs. For x²/9 − y²/16 = 1, enter y = 4√(x²/9 − 1) and y = −4√(x²/9 − 1), and add y = (4/3)x and y = −(4/3)x to see the asymptotes.
